182.2 × 191.6-16BB-N TOPCon single crystal double-sided battery
Front: 16 main grids, 12 positive segments, 180 secondary grids, main grid width 0.030 ± 0.02mm
Back: 16 main grids, 12 segments on the back, 208 secondary grids, main grid width 0.030 ± 0.02mm
Thickness: 130 ± 20um
Dimensions: 182.2mm × 191.6mm ± 0.5mm, Φ 262.5mm ± 0.5mm
Current temperature coefficient:+0.045%/K
Voltage temperature coefficient: -0.25%/K
Power temperature coefficient: -0.30%/K
